With the MCU intelligent control technology and power frequency transformer technology, the Three-phase Power Frequency Inverter can operate pure sine wave AC output for diverse loads perfectly.
With the MCU intelligent control technology and power frequency transformer technology, the Three-phase Power Frequency Inverter can operate pure sine wave AC output for diverse loads perfectly.
With the MCU intelligent control technology and power frequency transformer technology, the Three-phase Power Frequency Inverter can operate pure sine wave AC output for diverse loads perfectly.
The Three-phase Power Frequency Inverter is designed for many overall protection functions, including overload, short circuit, over/under voltage, and temperature safeguards, and it has wide range, high accuracy, and fully automatic voltage stabilization.
| Rated Power | 10KW, 15KW, 20KW, 8KW |
|---|---|
| Battery Voltage | 10KW, 15KW, 20KW, 8KW |
| Phase | Three-phase+N+G |
| Nominal Voltage | 220VAC±3% (Load Fluctuation), 380VAC±1% (Steady State Load) |
| Input Frequency Range | 50/60Hz±0.1Hz |
| Current Peak Ratio | 3:1 MAX |
| Output Waveform | Pure Sine Wave |
| Total Harmonic Distortion | Linear Load < 3%; Nonlinear Load < 5% |
| Instant Recovery Time | ＜10ms |
| Balance Load Voltage | ＜±1%；＜±5%（Unbalanced Load Voltage） |
| Overload Capacity | >130%: 1s, 100%~110%: 30s, 110%~130%: 10s |
| Inverter Efficiency | >89% |
| Communication Interface | RS232, RS485 |
| Operating Temperature | 0～40℃ |
| Relative Humidity | 30%～90% |
| Cooling Method | Forced Air Cooling |
| NoisedB | ≤58dB |
| Easy Maintenance | The Front, Upper, Left and Right Sides Can Be Opened |
| Dimension | 705*405*910MM |
| Net Weight (kgs) | 170 |
