HSPS-F High Frequency Inverter offers a wide PV input voltage range, making it adaptable to various solar setups. Designed to thrive even in challenging environments with an anti-dusk kit.
HSPS-F High Frequency Inverter offers a wide PV input voltage range, making it adaptable to various solar setups. Designed to thrive even in challenging environments with an anti-dusk kit.
Harnessing advanced high-frequency switching, HSPS-F High Frequency Inverter ensures seamless conversion, minimizing energy loss.
With a compact design, it offers versatility for various applications. Experience enhanced connectivity through smart features like WIFI&GPRS compatibility, allowing remote monitoring and control.
Equipped with an integrated MPPT solar charger, it optimizes power capture from solar panels. Designed for modern needs, it accommodates a wide PV input voltage range, making it adaptable to diverse solar installations.
Built to withstand harsh conditions, it includes features like anti-dusk kits for longevity. With intelligent battery charging, it maximizes battery lifespan, and its compatibility with lithium batteries opens doors to a greener future.
| Rated Output Power | 1500VA/1500W, 3200VA/3000W |
|---|---|
| Voltage | 230VAC |
| Selectable Voltage Range | 170~280VAC (For Personal Computers), 90~280VAC (For Home Appliances) |
| Frequency Range | 50Hz/60Hz(Auto Senting) |
| AC Voltage Regulation | 230VAC±5% |
| Surge Power | 3000VA, 6400VA |
| Efficiency (Peak) PV to INV | 97% |
| Efficiency (Peak) Battery | 94% |
| Transfer Time | 10ms(For Personal Computers);20ms(For Home Appliances) |
| Battery Voltage | 12VDC |
| Floating Charge Voltage | 13.5VDC, 27VDC |
| Overcharge Protection | 16VDC, 33VDC |
| Maximum Charge Current | 60A |
| Maximum PV Array Power | 2000W, 3000W |
| MPPT Range @ Operating Voltage | 90~430VDC |
| Maximum Charging Current | 80A |
| Maximun Efficiency | 98% |
| Dimension | 350*259*190MM |
| Carton Dimension | 272*423*348MM |
| Net Weight (kgs) | 5, 6 |
| Gross Weight (kgs) | 5.5, 6.5 |
| Communication Interface | GPRS, RS232, WIFI |
| Humidity | 5% to 95% Relative Humidity (Non Condensing） |
| Operating Temperature | -10~55℃ |
